Multi-Channel Operation

Marsis Ingest can record from HD SDI / SDI or IP sources. Each channel can be configured individually for different input type. Each encoder name can be assigned for multi-channel recordings such as CAM 1, CAM 2, CAM 3 or Sports Channel, News Channel etc.

Multi-Format Support

Marsis Ingest has wide range of recording format support. Majority of broadcast codecs and wrappers are included in the Ingest. Apple Prores, AVI, Mpeg, H.264(Mp4), HEVC, MOV, DV, MXF, GXF, DNxHD, MKV. FLV, WMV etc.

Advanced Scheduler

Marsis Ingest have built in Scheduler for event based recordings. Operators can make a recording list for each channel individually. These scheduled events can be Hourly for News Agency feeds.

Hardware Encoding

Marsis Ingest supports Intel Quick Sync, NVENC (cuda) and AMD AMF hardware encoding in H.264 and HEVC formats. This allows recording 8 full HD Channels in single CPU based system with proper graphics card.

Web Control

Marsis Ingest can be controlled from web browser. User can log in remotely and preview incoming video source. Recording can be start - stop - split from web interface.

Features

  • Live Inputs

    Live inputs can be SDI /HDMI input or IP Stream SRT, RTMP, UDP / NDI®. DirectShow. Supported Cards: Bluefish444, AJA, Blackmagic Decklink

  • Supported IP Inputs

    UDP, SRT, RTMP, HTTP, HLS, NDI® etc...

  • Multi Format

    Multiple popular broadcast and multimedia formats / codecs can be recorded.

  • Multi Channel

    8 Channel capture in SD / HD / 4K resolutions.

  • Multi Preset

    Ability to record 3 different preset from the single input source.

  • Built in Scheduler

    Built-in Advanced Scheduler makes recordings easy and unattended.

  • Time & Date Overlay

    Ingest has date and time overlay for compliance recordings.

  • 24/7 Recording

    Designed for 24/7 uninterrupted capture with automatic file split.

  • Audio Monitoring

    The system has selectable audio monitoring for the audio preview.

  • Hardware Encoding

    Ingest supports Intel Quick Sync, NVENC (CUDA) and AMD AMF encoding in H.264 and H.265 (HEVC) formats.

  • Web Client

    Operators can preview incoming feed and control ingest over web client.

  • Local Storage Recording

    Marsis Ingest can record directly to central storage and local storage at the same time.

  • Integrated Automation

    Ingest events can be triggered by Marsis Playout and works integrated with Marsis Media Asset Management system.

  • Supported Video Formats

    AVI, MPEG(PS/TS), H264/MPEG-4-AVC, HEVC(H265), MOV, Quicktime, MJPEG, DV, AVC-Intra, DVCPRO, XDCAM, DNxHD, MXF, GXF, LXF, MKV, FLV, WMV/ASF, ProRes, 3GPP, Divx, Xvid, F4V, Sorenson, JPG, PNG , BMP...

  • Supported Audio Formats

    AAC, ATSC A/52A (AC-3), ATSC A/52 E-AC-3, FLAC, MP2, MP3, ALAC, Ogg Vorbis, Wav, ADPCM etc...
